Test Force Resolution

0.001 kN

Accuracy of Force Measurement Range

2% FS - 100% FS

Static Test Force Accuracy

±0.5% FS

Displacement Resolution

0.001 mm

Relative Error in Displacement Measurement

±0.5%

Amplitude Stroke

±50 mm (Maximum stroke 100 mm)

Fatigue Frequency

0.1-10 Hz (According to the principle of amplitude-frequency characteristics, generally, the frequency will decrease when the amount of deformation is large)

Sampling Frequency

Supports real-time collection at 10 kHz

Test Waveform

Sine wave, sawtooth wave, and other waveforms

Fatigue Control Method 2

Constant Force Fatigue Test, with Deformation-Time Curve, Force Amplitude-Number of Cycles Curve, and Sine Wave Curve.

Fatigue Control Method 3

Programmable Control Method, allowing users to define test steps based on requirements, with the capability for variable amplitude cycling tests.
